   The STABO (STAbilized BOdy) ^[1] extraction harness was a device which allowed military personnel to be rescued (by helicopter) from field locations which prevented the conventional landing and boarding of a helicopter.
   It was designed and developed by U.S. Army Special Forces personnel stationed in Vietnam during the Vietnam War, and became a widely used, and highly successful extraction device employed during the Vietnam War.


   History

   Sergeant First Class Clifford L. Roberts, U.S. Army, Special Forces, drew up the first design on a napkin, after a wounded Special Forces Soldier fell out of a McGuire extraction rig, during a combat extraction mission. SFC Roberts used the unit's parachute loft, and made the first prototype on the sewing machines used to service and repair parachutes. He was then sent to present the design. The design was approved and 500 rigs were ordered. SFC Roberts was awarded a Bronze Star for the design. ^[2]
   The STABO harness/rig was a machine-stitched, skeletonized harness, very similar to that of a standard parachute harness. The harness webbing was made of heavy duty nylon, identical to the type used in the manufacture of parachute harnesses. The STABO rig served two main functions: it was itself an extraction harness and also served as the base for the operator's load bearing equipment in the field. Later versions of the STABO harness were made in small, medium and large sizes.


   Use

   To ready a STABO harness for rope extraction, the two leg straps (normally folded and stowed during ground operations (secured by utility tape or rubber bands)) were freed from the back of the harness, routed up between the legs, and each leg strap was then snapped onto a V ring, with one mounted on each lower front waist of the harness. A standard issue LBE pistol belt was laced through the center sections of the rig, and fastened around the operator's waist, which served as the main closure device for the overall rig on the operator.
   The operator was extracted using a dual rope (or strap) 'Y' design system (one per each STABO rig), lowered by a helicopter. Each strap end typically retained a large carabiner fastener, which was clipped to a large V or D ring permanently attached to each upper shoulder strap of the rig. Once both carabiners were attached to the upper V/D rings on the rig, the operator could then be lifted out vertically by the helicopter. (This extraction method was often referred to informally as the "strings" method.)
   The STABO rig was far more secure, safe and comfortable than the McGuire rig, and perhaps most importantly, it allowed the unrestricted use of the operator's hands, to operate any weapons during the frequently 'hot' extractions from a combat landing or pickup zone. Further, the rig was equally effective if an operator was wounded or unconscious.
   As the STABO rig was used as the base for operator's personal LBE harness, it was worn for the full duration of the combat operation, in which to allow for rapid extraction by the rope ("strings") method, if a conventional helicopter LZ could not be quickly established (which was frequently experienced in South East Asia, as reconnaissance teams were operating deep in heavily forested enemy territory).
   The current US Military method for extracting troops using the helicopter rope method, is the Special Patrol Insertion/Extraction (SPIE) system, a direct and close descendant of the STABO rig system that was developed and pioneered in Vietnam/SEA.


   References

   1.

3. Acronym as per Army Training Manual TM 10-1670-262-12&P (1993)
4.

According to 'U.S. Army Uniform of the Vietnam War", by Shelby Stanton, three US Army SF men contributed to the design, testing, and adoption of the STABO harness: Major Robert Stevens, Captain John Knabb, and SFC Roberts.

Developed at the MACV Recondo School in Vietnam, the STABO Harness was designed to enable the rapid extraction of reconnaissance personnel by helicopter. Named after its inventors, Maj. Robert L. Stevens, Cpt. John. D. H. Knabb and SFC. Clifford L. Roberts, the harness was made from type-13 nylon and formed an X across the back. In order to be extracted the soldier simply snapped the helicopter’s extraction line bridle to the two shoulder mounted D rings. This was a significant improvement on the McGuire Rig, which was essentially a 100-foot mountain rope anchored to the helicopter with a loop at the end for the individual to sit in. Unlike the STABO, riding the McGuire Rig required strength and agility and it was consequently of little use in extracting the wounded.

Equipped with a standard pistol belt, the harness was also designed in part to replace the M1956 / M1967 Load Carrying Suspenders. The STABOs leg straps were folded up and secured by tape or rubber bands against the shoulder straps until needed.

The first production STABO was supplied by the Counter Insurgency Support Office (CISO), which procured 500 harnesses (at a cost of $5 each) for Special Forces in March 1969. After completing safety tests and revising their cost estimates down from $100 to $14.50 per unit, Natick Labs was instructed in May 1970 to procure 1,370 harnesses for use by Army recon units in Vietnam. Both the CISO and Natick models were produced in small, medium and large sizes. However, the Natick STABO had several enhancements, including: padded shoulders, adjustable leg straps and a permanently sewn in pistol belt.¹

1. E308, ENSURE, Records of the U.S. Army Concept Team Activity, Records of the United States Forces in Southeast Asia, 1950-1975, Record Group 472, National Archives at College Park, MD
